Wellbore Trajectory Measurement System Downhole Imaging Inspection Camera Full Hole Wall Scanner

The GD-C1201 Intelligent Drillhole Optical Imager stands as a pinnacle of innovation in geotechnical and industrial imaging, engineered to deliver unrivaled accuracy, adaptability, and operational efficiency. Combining multisensor fusion, cloud-ready data workflows, and ruggedized hardware, this system empowers professionals to tackle complex subsurface inspections with confidence.

Core Competitive Advantages

1. Ultra-High-Definition Imaging: Leveraging a 1.34MP low-light CCD sensor and 30 Lux adjustable LED array, the system resolves 0.1mm cracks and micro-fractures, even in turbid or sediment-filled boreholes.

2. Dynamic 3D Compass: Achieves 0.1° azimuth accuracy and ±90° tilt detection, critical for mapping inclined or horizontal drillholes in mining and tunneling projects.

3. Seamless Data Integration: The TENSENSE2010 platform automates lithology logging, exports to GIS-compatible formats, and supports real-time collaboration via encrypted cloud sync.

4. Extreme Environment Resilience: Operates at -20°C to 40°C with IP67 waterproofing and 15MPa pressure tolerance, ideal for deep-sea or Arctic explorations.

5. Ergonomic Field Design: 1.8kg host and modular probes (Φ24mm–Φ65mm) enable rapid deployment in confined or remote sites.

Technical Specifications

Industry-Specific Solutions

• Hydrocarbon Exploration: Map reservoir fractures, assess cementing quality, and monitor wellbore trajectories with millimeter-level precision.

• Urban Infrastructure: Detect voids in bridge pilings, subway tunnels, and dam foundations using automated anomaly detection.

• Mineral Prospecting: Quantify ore vein geometries and structural discontinuities for optimized extraction planning.

• Environmental Remediation: Track contaminant migration paths in groundwater wells via time-stamped digital logs.

• Renewable Energy: Inspect geothermal well integrity and offshore wind turbine anchor points.

Differentiators from Conventional Systems

• Edge Computing Capability: ARM+DSP dual-core processing eliminates reliance on external computers, reducing setup time by 50%.

• Interdisciplinary Versatility: Compatible with boreholes from Φ25mm to Φ500mm, including vertical, horizontal, and multidirectional configurations.

• Regulatory Compliance: Meets ATEX Zone 1/2 standards for explosive atmospheres and ISO 9001 quality benchmarks.

• Scalable Data Outputs: Generate compliance-ready reports in Excel, AutoCAD, or LAS formats for regulatory audits.
